POWER CONTACTOR | 25 / 35KW / HP | 50 A | 1 NO + 1 NC | M7 (220V) | LC1D50AM7

POWER CONTACTOR | 25 / 35KW / HP | 50 A | 1 NO + 1 NC | M7 (220V) | LC1D50AM7

SKU ID: E21003.0000008.00

Review: 0 Ratings

Brand: Schneider

  • AC-3 Duty - KW/HP

    25 / 35

  • Current rating - A

    50

  • Auxiliary Contacts

    1 NO + 1 NC

  • Coil voltage code

    M7 (220V)

  • Model no

    LC1D50AM7

  • Model

    TeSys Deca

  • Contactor application

    Resistive load, Motor control

  • Utilisation category

    AC-1, AC-3, AC-3e, AC-4

  • Rated operational voltage

    <= 690 V AC; <= 300 V DC

  • Control circuit voltage

    110 V AC 50/60 Hz

  • Protective cover

    With

  • Associated fuse rating - Power

    80 A gG (Type 1 & 2)

  • Associated fuse rating- Signal

    10 A gG

  • Average impedance

    1.5 mOhm at 50 Hz

  • Power dissipation per pole

    2.4 W (AC-3/AC-3e), 5.4 W (AC-1)

  • Rated insulation voltage

    690 V (IEC), 600 V (UL/CSA)

  • Overvoltage / Pollution degree

    III / 3

  • Rated impulse withstand voltage

    6 kV (IEC 60947)

  • Safety reliability - Nominal

    1.4 Mcycles

  • Safety reliability - Mechanical

    20 Mcycles

  • Mechanical durability

    6 Mcycles

  • Electrical durability

    1.5 Mcycles AC3/3e; 1.4 Mcycles AC1

  • Control circuit type

    AC at 50/60 Hz standard

  • Coil technology

    Without built-in suppressor module

  • Control circuit voltage - Drop-out

    0.3...0.6 Uc 50/60 Hz

  • Control circuit voltage - Operation

    0.8...1.1 Uc 50/60 Hz

  • Inrush/Hold-in power consumption

    160-140 VA / 15-13 VA

  • Heat dissipation

    4...5 W at 50/60 Hz

  • Operating time

    Closing 12-26 ms; Opening 4-19 ms

  • Maximum operating rate

    3600 cycles/hour at 60 °C

  • Connections - terminals

    Wire sizes up to 35 mm²

  • Auxiliary contacts type

    Mechanical and Mirror type

  • Minimum switching current

    5 mA for signalling circuit

  • Non-overlap time

    1.5 ms

  • Mounting support

    Rail, Plate

  • Standards

    EN/IEC 60947-4-1, EN/IEC 60947-5-1

  • IP degree of protection

    IP20 front face (IEC 60529)

  • Protective treatment

    TH (IEC 60068-2-30)

  • Permissible ambient air temperature

    -40…70 °C with derating

  • Operating altitude

    0...3000 m

  • Fire resistance / Flame retardance

    850 °C (IEC 60695-2-1) / V1 (UL 94)
